DC Gearmotor, 710 in-lb Max. Torque, 6.5 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 6.5 RPM Nameplate RPM, 90V DC Voltage
DC Gearmotor, 710 in-lb Max. Torque, 6.5 RPM Nameplate RPM, 90V DC Voltage

DC Gearmotor, 710 in-lb Max. Torque, 6.5 RPM Nameplate RPM, 90V DC Voltage

  • Dayton
  • DC Gearmotor, Shaft Orientation Parallel, Motor Enclosure Totally Enclosed Nonventilated, Operating Voltage 90V DC, Motor Type Permanent Magnet DC, Nameplate Speed 6.5 RPM, Maximum Torque 710 in-lb, Overhung Load Capacity 900 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Gear Ratio 276:1, Input Horsepower 1/6 hp, Output Shaft Diameter 3/4 in, Bearing Type Ball on Motor, Needle Throughout

    graingerSKU: 2H592, mscSKU: , zoro_no: G0367814, mongo_id: 65bbe80e22d7a989a98d3da6

Web Price
$947.49 / each
Qty

Product Details

Ball on Motor, Needle Throughout
Ball on Motor, Needle Throughout with Thrust Balls on Case
Externally Replaceable
United States
12.43 in
3.13 in
4.67
TENV
1 A
1 A
Die Cast Aluminum
Hardened Steel
276:1
Helical, Spur
Totally Enclosed Nonventilated
All Angle
CW/CCW
Parallel
Single
DC Gearmotor
90V DC
Aluminum
1/6 hp
1/6
12.5 in
Permanent Heavy Fluid Gear Oil
40 Degrees C
710 in-lb
40 Degrees C
710 in-lb
Totally Enclosed Nonventilated
Permanent Magnet DC
All Position
Any Angle
6.5 RPM
6.5 RPM
90V DC
3/4 in
1 7/8 in
14.38 in
900 lb
900 ft-lb
1
Yes
Yes
6YHY6
No
CW/CCW
0 to 15
Plastic
Spring Loaded Lip Type on Input and Output Shaft
Spring Loaded Lip Type on Input and Output Shaft
3/4 in
1-7/8
Parallel
C-UL Recognized, UL Recognized
Yes
None
90VDC
