Home / AC Gearmotor, 687.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 208-230/460V AC Voltage, 3 Phase
AC Gearmotor, 687.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 208-230/460V AC Voltage, 3 Phase
AC Gearmotor, 687.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 208-230/460V AC Voltage, 3 Phase

AC Gearmotor, 687.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 208-230/460V AC Voltage, 3 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type 3-Phase, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 27 RPM, Maximum Torque 687 in-lb, Overhung Load Capacity 325 ft-lb, Rotation CW/CCW, Output Shaft Height 3 in, Mounting Orientation Any Angle, Operating Voltage 208-230/460V AC, Inverter Rated Yes, Gear Ratio 64:1, Brake Type None, Shaft Orientation Parallel, AGMA Gear Class Class 9

    graingerSKU: 4Z384, mscSKU: , zoro_no: G3004364, mongo_id: 65bbe8b222d7a989a990d403

Web Price
$1,356.24 / each
Qty

Product Details

Class 9
Ball on Motor, Heavy Duty Ball, Needle Roller and Thrust Balls on Case
Ball on Motor, Heavy Duty Ball, Needle Roller and Thrust Balls on Case
Adaptable to 2LYV2
None
United States
TEFC
60 Hz
1.32/0.66
1.32/0.66 A
Die Cast Aluminum
Hardened Steel
64:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
3
CW/CCW
Parallel
Single
AC Gearmotor
208-230/460V AC
1st Stage Helical, AGMA Class 9, Hardened Steel, Subsequent Stages Spur
Die Cast Aluminum
Die Cast Aluminum
60 Hz
0.33 hp
1/3 hp
Yes
63.5:1
1/8 in
3/16 in
12.31 in
Permanent Heavy Duty Gear Oil
40 Degrees C
687 in-lb
104 Degrees F
687 in-lb
Totally Enclosed Fan-Cooled
3-Phase
2.5 in
7.13 in
Any Position
All Position
Any Angle
27 RPM
27 RPM
1
208-230/460V AC
3/4 in
3 in
1 1/2 in
6.63 in
8.13 in
325 lb
325 ft-lb
1
Three
CW/CCW
16 to 30
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
3/4 in
1.5
Parallel
CSA Certified, UL Recognized
None
208-230/460
